HAILIJU Automatic computer cutting saw (touch screen, with side support) Model: BS928
Automatic computer cutting saw (touch screen, with side support)
Model: BS928
Automatic computer cutting saw (touch screen, with side support)
Model: BS928
Product parameter
Cutting width 2800mm Working thickness 120mm
Positioning mode Automatic positioning accuracy ±0.02mm
Sawing accuracy ±0.15mm Main saw motor power 15kw
Outer diameter of main saw blade 400mm Diameter of main saw shaft 75mm
Main saw speed 4100 r/min Power of saw car traction motor 2.0kw
Manipulator servo motor 2.0kw Auxiliary saw motor power 1.5kw
Outer diameter of auxiliary saw blade 200mm Diameter of auxiliary saw shaft 45mm
Auxiliary saw speed 6200 r/min Feeding speed 0-100 M/min
Blade speeds 0-100 M/min Return speed 0-120 M/min
Air pressure 0.6-0.8 MPA Centrifugal fan 3kw
Total power 23.5kw Operating table thickness Main25mm、Vice-16mm
1m internal error of gear rack 0.02mm Pressing method Cylinder clamp pressing
Color standard Blue and white color Machine weight 6350kg
Cabinet size Host：5200*1450*2100
Parts：3600*800*1900
Automatic computer cutting saw (touch screen, with side support) Model: BS928
Product details
01.
Integrated processing, strong stability, high stability body structure design. The table top is made of 28mm integrated plate and fixed on the left and right frame beams to ensure excellent balance and straightness.
02.
Independent movement, convenient adjustment, high speed, stability and flexibility. The movement of independent main saw and scribe saw can automatically adjust the sawing height with the sawing thickness.
03.
High speed processing, efficiency ahead of CPU control motherboard. The third generation of micro programmable controller,built-in up to 64K large capacity RAM memory, built-in industry's highest level high-speed processing 0.065 μ S / basic command,built-in independent 3-axis 100kHz positioning function (transistor output type).
04.
Optimize material opening, save plate joint development, and have powerful functions. Configure industrial control computer,HHM control software, edit and manage sawing scheme, prepare and manage sawing tasks, simulate and execute sawing,and be compatible and integrated with various sawing optimization software, bar code management software and factory automation software.
05.
Fault self inspection, leading automatic fault detection technology for safety production.The operation of the machine is to automatically monitor all parts and components and transmit signals to the central processor.Once a part is released for alarm, the PC will display the corresponding fault and the machine will stop working to ensure the safety of the operators.
06.
Double finger clamping, accurate feeding with cylinder clamping. The industry-leading double finger clamping structure is adopted.The plate clamping adopts the air cylinder, and the feeding advances through the roller bed surface. The feeding is accurate,ensuring the cutting accuracy of the fixed size sawing and will not damage the workpiece surface.
Automatic computer cutting saw (touch screen, with side support)
Model: BS928
Certificate
